There’s been a lot of services released lately that aim to assist developers share their local development environments over the internet. localtunnel, showoff.io and pagekite come to mind, just to name a few. However, you can roll your own forwarding service if you have SSH access to a server running Apache fairly easily.
The Big Picture
First, setup a webserver to listen for connections to demo.example.com. When a user connects to the webserver, it will attempt to proxy their request to port 1337 (demo.example.com port 1337).
Second, a reverse proxy initiated with SSH on your localhost creates a connection to demo.example.com, and then has all traffic on demo.example.com port 1337 forwarded to localhost port 80.
User => demo.example.com:80 <=> demo.example.com:1337 <=> localhost:80
- Apache Web Server
- Apache mod_proxy module
- Local web application
- SSH client
- SSH public/private keys to login to the remote server
Server Setup (Ubuntu)
You should be able to login to your server over SSH using public/private key authentication. How to do that is out of scope for this post, however there are plenty of guides available online that explain in detail how to do this.
Apache: Enable mod_proxy
$ sudo a2enmod proxy_http
Apache: Configure VirtualHost
Setup Apache to use a VirtualHost for URL you want to use for sharing your work:
ProxyPass / http://127.0.0.1:1337/
ProxyPassReverse / http://127.0.0.1:1337/
Apache: Restart to load VHost
$ sudo apachectl restart
Make sure you’re running a local web application
This should be pretty obvious It doesn’t matter what port it’s running, you can configure that when you start the SSH reverse proxy.
Create an SSH Reverse Proxy
To actually enable the connection form your public web server to your localhost, you have to create a reverse proxy using SSH. The reverse proxy will create a connection from your localhost to the remote server (demo.example.com), then have all traffic from a designated remote port forwarded to a local port.
$ ssh -fNR 1337:localhost:80 demo.example.com
-fputs ssh into the background. If you want to be able to easily kill the Proxy later, omit the -f and use
ctrl + c.
-Ndisables all output keeping things clean. If you omit this, you’ll see SSH connect to your remote server.
-R 1337:localhost:80Tells SSH to create a reverse proxy and that all traffic on the remote port 1337 should be forwarded to localhost’s port 80.
demo.example.comis the remote server you want SSH to connect to.
You may need to change your localhost port depending on what port your local environment is running on. For example: if you’re developing a rails application using the builtin webserver, you might need to use port 3000 instead of port 80.
You should now be able to hit demo.example.com in your browser, and see your application load.
